| Technique parameter | ||||
| Description | Metric | Imperial | ||
| Length x width x height | 2365x1020x2250 | mm | 93x40x88 | in |
| Dry Weight | 1430 | kg | 2860 | lb |
| Operating weight | 1580 | kg | 3470 | lb |
| Forward drum width | 900 | mm | 35.4 | in |
| Forward drum diameter | 560 | mm | 22 | in |
| Back drum width | 900 | mm | 35.4 | in |
| Back drum diameter | 560 | mm | 22 | in |
| Water tank capacity | 150 | l | 39 | US gal |
| Shipping weight (including packaging) | 1570 | kg | 3450 | lb |
| Drive method | Variable plunger pump constant displacement hydraulic motor | |||
| Walking method | Forward & Backward | |||
| Vibrating clutch method | Gear pump, gear motor | |||
| Shipping size | 2462×1120×1800 | mm | 97x28.4x45.7 | in |
| Engine Type | perkins 403d-11 or Honda GX630 | |||
| Starting system | By electric | |||
| Displacement | 1028 | cm3 | 62.7 | in3 |
| Fuel consumption | 3.7 | l/h | 1 | US gal/h |
| Fuel tank capacity | 30 | l | 8 | US gal |
| Hydraulic tank capacity | 38 | l | 10 | US gal |
| Dynamic (centrifugal) force | 13 | kN | 2925 | lb |
| Frequency | 65 | Hz | 3900 | vpm |
| Static linear force per drum (f/r) | 5.5/6.6 | N/mm | 32/38 | lb/in |
| Dynamic linear force per drum (f/r) | N/mm | lb/in | ||
| Variable speeds - Forward | 0-8 | km/h | 0-5 | mph |
| Variable speeds - Forward | 0-120 | m/min | 0-430 | ft/min |
| Variable speeds - Reverse | 0-4 | km/h | 0-2.5 | mph |
| Variable speeds - Reverse | 0-67 | m/min | 0-220 | ft/min |
| Grade ability without vibration | 30 | % | 30 | % |
| Max. area capacity | 7.458 | m2/h | 80.218 | ft2/h |
| Sprinkling system | Gravity Fed | |||
| Fuel type | Gasoline | |||
| Static weight per drum (f/r) | 650/780 | kg | 1430/1720 | lb |
