| Description | Metric | Imperial | ||
| Length x width x height (handle in working position) | 1650x 1100 x 1000 | mm | 65.0 x 43.3 x39.4 | in |
| Dry Weight | 530 | kg | 1166 | lb |
| Operating weight | 583 | kg | 1283 | lb |
| Forward drum width | 600 | mm | 23.5 | in |
| Forward drum diameter | 450 | mm | 17.8 | in |
| Back drum width | 600 | mm | 23.5 | in |
| Back drum diameter | 450 | mm | 17.8 | in |
| Drive method | Static hydraulic drive unit | |||
| Walking method | return | |||
| Vibrating clutch method | Mechanical drive, electromagnetic clutch | |||
| Water tank capacity | 50 | l | 13.2 | US gal |
| Shipping weight (including packaging) | 590 | kg | 1298 | lb |
| Shipping size | 1850x1200x1150 | mm | 72.8 x 47.2 x 45.3 | in |
| Engine Type | Diesel engine,air-cooled,4 stroke, vertical type, single cylinder | |||
| Starting system | Hand crank | |||
| Max. Rated Power @ Rated Speed* | 9.0 @ 3600rpm | |||
| at | 2.6 | 1/min | 2,600 | rpm |
| Operating speed | 2.6 | 1/min | 2,600 | rpm |
| Fuel consumption | 1,67 | l/h | 0.44 | US gal/h |
| Fuel tank capacity | 3.5L | l | 0.93 | US gal |
| Hydraulic tank capacity | 30 | l | 8 | US gal |
| Dynamic (centrifugal) force | 20 | kN | 4,500 | lb |
| Frequency | 70 | Hz | 4,200 | vpm |
| Static linear force per drum (f/r) | 5/7,5 | N/mm | 29/43 | lb/in |
| Dynamic linear force per drum (f/r) | 10,0/10,0 | N/mm | 57/57 | lb/in |
| Variable speeds - Forward | 0-4,0 | km/h | 0-2.5 | mph |
| Variable speeds - Forward | 0-67 | m/min | 0-220 | ft/min |
| Variable speeds - Reverse | 0-2,0 | km/h | 0-1.2 | mph |
| Variable speeds - Reverse | 0-32 | m/min | 0-105 | ft/min |
| Grade ability without vibration | 30 | % | 30 | % |
| Max. area capacity | 2.613 | m2/h | 28,115 | ft2/h |
| Sprinkling system | gravity fed | |||
| Fuel type | gasoline | |||
| Static weight per drum (f/r) | 200/250 | kg | 440/550 | lb |
