| Model | SD-10 |
|
payload |
1000kgs |
|
unloading system |
mechanical |
|
chassis |
chassis constructed from folded mild steel,robust and sturdy to with stand various working conditions |
|
skip capacity |
550 litres |
|
diesel engine type |
single cylinder, water-cooled diesel engine with radiator |
|
Engine brand / power |
CHANGCHAI/13.8HP YANMAR/17.7HP |
|
Engine Starting system |
Hand start |
|
Gearbox |
3 forward and 1 reverse speed control the Joystick |
|
Drive |
4x2 |
|
speed(Max.) |
23km/h |
|
Gradient(with full load) |
21% |
|
turning radius(m) |
3.5m |
|
tyres |
front 7.50-16 Rear:5.00-15 |
|
Driver's Cab |
without |
|
Weight |
1000kgs |
|
Dimensions in Container |
2300X1450X1800mm |
