TECHNICAL SPECIFICATIONS |
SD-20Y |
SD-30Y |
Payload (kg) |
2000 |
3000 |
Unloading system |
Hydraulic tipping, frontal |
Chassis |
Articulated |
Skip capacity (lires) |
Water |
800 |
1200 |
Levelled |
1000 |
1500 |
Heaped |
1400 |
2050 |
Diesel Engine |
Brand |
Lijia |
DEUTZ |
XINCHAI |
DEUTZ |
Power (hp) |
28.9 |
27 |
49.4 |
50 |
N° of Cylinders |
2 |
4 |
3 |
Cooling system |
Water |
Air |
Water |
Air |
Engine Starting System |
Electric, 24 Volts Battery |
Gearbox |
Mechanical gearbox. 3 forward gears and 1 reverse. |
Planetary reduction axles besides on differential output. |
Drive |
4×4 |
Speed (max.) (km/h) |
25 |
26 |
Gradient (with full load) |
35° |
36° |
